RedDot : E-6100 Roof top Electric Air Conditioner Unit 12V E-6100-0-12P & 24V E-6100-0-24P
E-6100 Rooftop
Electric Air Conditioner Unit
Red Dot has created a 3kW electric rooftop unit for use on heavy, medium and light duty trucks, construction and agricultural cabs. the E-6100 electric rooftop air conditioner is a self-contained unit incorporating a condenser, compressor and evaporator core.
This model is self-contained and does not require a compressor driven off the engine.
Please contact us to discuss your specific requirements.
12 volt variant specification
E-6100 SPECIFICATIONS (12 volt variant) | |
BTUs | 12v - 11,900 |
AIR FLOW | 299 CFM |
WEIGHT | 100lbs |
DRAW | 60 - 100 amps |
24 volt variant specification
E-6100 SPECIFICATIONS (24 volt variant) | |
BTUs | 24v - 15,000 |
AIR FLOW | 299 CFM |
WEIGHT | 100lbs |
DRAW | 60 - 100 amps |
E-6100 SYSTEM ORDERING GUIDE | ||
| R134a |
NOTES |
UNITS | E-6100-0-12P E-6100-0-24P | 12VDC 24VDC |
CONDENSER | Contained in E-6100 unit | |
COMPRESSOR | Contained in E-6100 Replacement Compressor 12v – RD – 2 – 7777 – 1P 24v – RD – 2 – 7777 – 1P | |
